[smc1500ic]

APC SMC1500IC

APC Smart-UPS C 1500VA LCD 230V with SmartConnect

Output

Output power capacity 900 Watts / 1.5 kVA
Max Configurable Power (Watts) : 900 Watts / 1.5 kVA
Nominal Output Voltage : 230V
Output Voltage Distortion : Less than 5% at full load
Output Frequency (sync to mains) : 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
Topology : Line Interactive
Waveform type : Sine wave
Output Connections : (8) IEC 320 C13 (Battery Backup)

Input

Nominal Input Voltage : 230V
Input frequency : 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections : IEC-320 C14
Input voltage range for main operations : 180 - 287 V
Input voltage adjustable range for mains operation : 170 - 300 V
Other Input Voltages : 220, 240

Battery

Typical recharge time : 3 hour(s)
Battery type : Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Replacement Battery : RBC6 RBC Quantity : 1
Battery Volt-Amp-Hour Capacity : 220

Communication & Management

Interface Port(s) : USB
Control panel : Multi-function LCD status and control console Audible Alarm Alarm when
on battery : distinctive low battery alarm : configurable delays Emergency Power Off (EPO)

Surge Protection and Filtering

Surge energy rating : 459 Joules
Filtering : Full time multi-pole noise filtering : 0.3% IEEE surge let-through :
zero clamping response time : meets UL 1449

Physical

Maximum Height : 219 , 21.9 CM Width : 171 , 17.1 CM Depth : 439 , 43.9 CM
Net Weight : 24.09 KG
Color : Black

Environmental

Audible noise at 1 meter from surface of unit : 45.0 dBA
Operating Temperature : 0 - 40 ?C
Operating Elevation : 0-3000 meters
Operating Relative Humidity : 0 - 95 %
Storage Temperature : -15 - 45 ?C
Storage Elevation : 0-15000 meters
Storage Relative Humidity : 0 - 95 %
Online thermal dissipation : 135.0 BTU/hr
Conformance
Approvals : C-tick, CE, GOST, VDE
Standard warranty : 3 Year Warranty Onsite Swap by APC Thailand

[SMC1500IC APC]

This product is part of the Smart-UPS range, an intelligent and efficient network power protection offer from entry-level to scalable runtime. This 1500VA/900W line-interactive UPS provides pure sine wave power to support critical electronics during power disruptions. The tower mount SMC has a SmartConnect port for cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and email notifications with recommended actions. The PowerChute Business Edition provides unattended shutdown of servers and workstations via serial or USB cables. It comes with IEC 320 C14 input, 8x IEC 320 C13 outlets, and 2x IEC jumper cables. This UPS has built-in lead-acid battery and is covered by a 2-year UPS warranty. Its dimensions are 439mm (depth) x 219mm (height) x 171mm (width) and weighs 20.1kg. Ideal for entry-level servers, networks, business VoIP, retail point-of-sale, edge networks and business desktops. It conforms to CE, C-Tick, GOST, VDE, and UL 1778.

เครื่องสำรองไฟ apc smc1500ic มาพร้อมกับฟังก์ชั่น smartconnect ที่ทำให้เราสามารถดูสถานะของเครื่องผ่าน cloud โดยไม่ต้องใส่ network card. apc ups รุ่นนี้มีกำลังไฟ 1500va 900 watts เป็นแบบ line interactive ลักษณะของเครื่องจะเป็นทรงตั้ง ( tower) มีปลั๊กขาออก จำนวน 8 ช่อง apc smc1500ic ราคาไม่แพง เหมาะกับ computer, server ตัวเล็ก และ อุปกรณ์ที่กินไฟไม่มาก การรับประกัน 3 ปี onsite service ทั่วประเทศ
