[SMC2000I]

APC SMC2000I

APC Smart-UPS C, Line Interactive, 2000VA, Tower, 230V, 6x IEC C13+1x IEC C19 outlets,
USB and Serial communication, AVR, Graphic LCD

Main Input Voltage 230 V
Other Input Voltage 220 V 240 V
Main Output Voltage 230 V
rated power in 1300 W
rated power in 2000 VA
Input Connection Type IEC 320 C20
output connection type 6 IEC 320 C13,1 IEC 320 C19
number of rack unit 0U
battery type Lead-acid battery
provided equipment CD with software,Documentation CD,USB cable

General

Number of power module filled slots 0
Number of power module free slots 0
product web sub-family Entry level
redundant No

Physical

colour Black
height 21.6 cm,width 17 cm,depth 44 cm
net weight 27.5 kg
mounting location Front
mounting preference No preference
mounting mode Not rack-mountable
two post mountable 0
USB compatible Yes

Input

input voltage limits 170...300 V adjustable, 180...287 V
network frequency 47...63 Hz

Output

harmonic distortion
Less than 5 % at full load
Maximum configurable power in 2000 VA
Maximum configurable power in 1300 W
UPS type Line interactive
Wave type Sine wave
output frequency
50 Hz sync to mains
Conformance

product certifications

C-Tick, CE, EAC, GOST, SABS, VDE

standards

EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental

acoustic level 45 dBA
heat dissipation 135 Btu/h
operating altitude 0...10000 ft
ambient air temperature for operation 0…40 °C
ambient air temperature for storage -15…45 °C
storage altitude 0.00…15240.00 m
relative humidity 0…95 %
storage Relative Humidity 0…95 %

Batteries

extended runtime 0
number of battery filled slots 0
number of battery free slots 0
Battery recharge time 3 h
number of battery replacement quantity 1
battery life 3…5 year(s)
Replacement battery APCRBC148
Battery power in VAH 499 VAh runtime
battery charger power 166 W rated
Communications & Management

alarm

Alarm when on battery : distinctive low battery alarm : configurable delays
control panel Multifunction LCD status and control console
free slots 0
Surge Protection and Filtering
Surge energy rate 300 J
noise suppression
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Warranty 2 years repair or replace

[SMC2000I APC ]

This product is part of the Smart-UPS range, an intelligent and efficient network power protection offer from entry-level to scalable runtime. This 2000VA/1300W line-interactive UPS provides pure sine wave power to support critical electronics during power disruptions. The tower mount SMC operates in green mode for high operating efficiency. It comes with IEC 320 C20 input, 6x IEC 320 C13 and 1x IEC 320 C19 outlets. This UPS has built-in lead-acid battery and is covered by a 2-year UPS warranty. Its dimensions are 440mm (depth) x 216mm (height) x 170mm (width) and weighs 27.5kg. Ideal for entry-level servers, networks, business VoIP, retail point-of-sale, edge networks and business desktops. It conforms to CE, C-Tick, GOST, EAC, SABS and VDE.

Brings the reliability of the world's most popular network and server UPS to entry level applications.
The most affordable true sine-wave UPS's in the Smart-UPS family.
Designed for entry level servers, it is compatible with today's active power factor corrected(PFC) power supplies. Included powerchute business Edition sofware is compatible with all major server operating systems and provides UPS management and safte system shutdown
